MAC Center Lathe
MAC Center Lathe
Contact us for price
Location:Pretoria, South Africa
orCall (012) 546 - 5616
Description
Extras:
3 jaw chuck, 4 jaw chuck, Dead center and center sleeves, tools, oil guns, splash guard, oil tray, face plate, steady rest, follow rest, face plate, coolant,English manual
This info is to best of our knowledge, but is not binding in detail.
Specifications
| Model | CS6250 |
| Condition | Used |
| Swing over bed | 500mm |
| Swing over cross | slide 300mm |
| Swing over gap | 710mm |
| Distance between centers | 1500 |
| Spindle nose | ISO702/11 No.8 cam lock |
| Main spindle bore diameter | 105mm |
| Spindle speed | 30-1600rpm, 24speeds |
| Taper of spindle nose | 113mm MT6 |
| Cross slide travel | 320mm |
| Compound slide travel | 145mm |
| Max. size cutting tool | 25mm x 25mm |
| Spindle travel | 150mm |
| Tail-stock taper of center | MT5 |
| Bed width | 390mm |
| Bed pitch of lead-screw | 120mm or 2TPI |
| Main drive motor | 10HP(7.5KW) |
| Coolant pump motor | 90W |
| Rapid traverse motor | 250W |
